Ecoflow 500W Alternator Charger

Ecoflow 500W Alternator Charger

SKU:EFALTCHRG500W

Regular price $599.00
Regular price Sale price $599.00
Sale Sold out
Tax included. Shipping calculated at checkout.

Available to Order, please contact us for an ETA

Warranty: LIMITED 2 YEAR



EcoFlow 500W Alternator Charger, charge while you drive, and stay powered up on the road.

Note: When installing the Alternator Charger main unit, make sure not to block the power button. After connecting the Alternator Charger to the portable power station (both RIVER and DELTA Series) via the XT60 port, you need to press the power button each time you turn on the car to turn it on before initiating charging through the app.

  • 500W alternator charger, 5x faster than traditional in- vehicle auxiliary power outlets. 500W(45A@12V*) input, 2.1 hrs to fully charge 1kWh (85Ah@12V).
  • A 3-in-1 fast charger, maintainer, and jump starter keeps your battery in mint condition.
  • Third party portable power stations are applicable.
  • 3-step easy installation
  • Suitable for a variety of vehicles, including SUVs, pickups, and RVS.
  • Expands existing RV house battery capacity.

Top up 1kWh (85Ah@12V) in only 2.1 hours

Charge 5× faster while you drive with our EcoFlow 500W Alternator Charger and recharge your power station in only 2.1 hours.With the EcoFlow 500W Alternator Charger, charge 5 times faster than with traditional vehicle auxiliary power outlets simply by using excess energy generated by your vehicle. The charger uses its onboard DC-DC converter to restore your EcoFlow power station's energy while you drive.

Triple the value with a 3-in-1 functional design

The 3-in-1 charger, maintainer, and jump starter saves time, money, and precious in-vehicle space. With its smart and efficient fast charging capabilities, you'll stay powered no matter how long you're on the road.

Compatible with all EcoFlow and most third-party power stations

Compatible with an XT60 connection, designed to charge EcoFlow RIVER, DELTA Series, and most third-party power stations. The charger's 500W fast-charging is compatible with most SUV, Pickup, and RV alternators, meeting diverse short-trip car camping power needs.

Extend your 4WD battery runtime

Conveniently adapts to 12V/24V 4WD batteries. Connects to EcoFlow portable power stations and protects 4WD batteries while expanding energy storage capacity by up to 7.2kWh*.* With EcoFlow DELTA 3 Pro and DELTA 3 Pro Extra Battery.

Safety-assured for any journey

With a high thermal resistance, Gallium Nitride (GaN) technology ensures safe charging every single time. The 500W Alternator Charger offers multiple safety features, including undervoltage protection that prevents excessive energy use and damage to the starting battery. A 2-year warranty ensures your experience and peace of mind.

Specifications

Model: EF-MS-H02-1
Net Weight: 5.7 kg
Dimensions (W × D × H): 242×194×35 mm
Wi-Fi: Frequency: 2412MHz-2472MHz; Maximum output power: 18.22dBm
Bluetooth: Frequency: 2402MHz-2480MHz; Maximum output power: 7.89dBm
Charging Mode: Input: 12V/24V⎓(11V-31V⎓), 45A Max.; Output: 40V-60V⎓, 500W
Max: 24V⎓, 360W Max.
Battery Maintenance Mode: Input: 40V-60V⎓, 3A Max.; Output: 13.8V/27.6V⎓, 100W Max.
Reverse Charging Mode: Input: 40V-60V⎓, 13.2A Max.: Output: 13.8V/27.6V⎓, 500W Max.
Fuse's Rated Current: 125A
Protection Type: Reverse polarity protection / Overcurrent protection / Short circuit protection / Overvoltage and undervoltage protection (Provided with integral protection against overloads)

Important notes:

* The 500W Alternator Charger includes only XT60i cable in the box and does not support reverse charging & battery maintenance functions with XT60 cable. To enable reverse charging & battery maintenance functions, additional purchase of XT150 cable is required.

When used with third-party portable power stations, the 500W Alternator Charger does not support reverse charging & battery maintenance functions.

* A DELTA Pro to Smart Generator Adapter is required to connect the Alternator Charger with DELTA Pro.

*When using an XT60 cable, the Alternator Charger switch on the device must be manually turned on and the charging function enabled in the app before charging can begin. Therefore, if planning to use the XT60 cable for output, avoid concealed installation of the Alternator Charger in advance.

⚠️ Important Information: You are responsible for LVV compliance of purchased products and their installation, if applicable. Images are for illustration only, actual product may vary. Please contact us with any questions.
